Does the SL1 lift glass or just transport it?

It lifts. The mast raises a panel to 60 in (152 cm), and the glass holder rotates, so you can take a panel off a rack upright and set it flat on a work table.

How many people are needed to operate it?

One. The SL1 is built so a single person can unload, move and set a panel of up to 180 lb (82 kg).

Will it fit through a doorway?

Yes. Shift the glass holder aside and the SL1 passes through a narrow doorway.

What is the heaviest panel it can take?

180 lb (82 kg). For heavier glass, look at the GT1 (400 lb) or the GRM250 (550 lb).

What warranty and support does Site Handling provide?

The SL1 comes with a 12-month parts and labour warranty. Site Handling aims to reply to quote requests within 1 business day, prices in CAD, and handles customs and warranty claims directly, so you deal with one Canadian company.

Glass Lifting & Handling Equipment

Glass Carrier SL1

Name: Glass Carrier SL1
Brand: K.S.F.
Price: 5800 CAD
Availability: InStock

Manual glass carrier: 180 lb, lifts to 60 in, rotating vacuum glass holder

Max Load

82 kg / 180 lb

Lifting Height

152 cm / 60 in

Unit Weight

66 kg / 146 lb

Operation

One person

Starting at $5,800 CAD+ applicable taxes

Ordering 3+ units?

Customs handled12-month warrantyQuote aim: 1 business day

Built for This Work

The SL1 takes a glass panel off the rack, turns it and sets it down, with one person doing the work. The detachable vacuum holder rotates a full 360°, so a panel goes from upright on the rack to flat on the work table without being handled.

Rated for panels up to 180 lb (82 kg). The mast lifts to 60 in (152 cm), 10 in solid wheels roll over rough site ground, and with the holder shifted aside the SL1 fits through a narrow doorway.

Applications

Unloading glass from racks
Moving panels between the shop, the truck and the install area
Setting panels flat on a work table

Compatible Materials & Surfaces

Standard glass panels (smooth surfaces)
Tempered and laminated glass

Restrictions

Panels up to 180 lb (82 kg)
Smooth, non-porous surfaces for the vacuum cups

Technical Details

Model Number	SL1
Dimensions	163 × 76 × 168 cm (64 × 30 × 66 in)
Glass Holder	Detachable vacuum holder, rotates 360°
Wheels	10 in solid
Warranty	12 months parts and labour
